Place of Origin:
Zhejiang, China
Brand Name:
PASSIONCO HOSE
Certification:
CE, RoSH
Model Number:
PFR-06
Description:
Multi-Purpose EPDM Rubber Hose is a versatile and durable hose designed for use in various industrial and agricultural applications. It is made from EPDM (Ethylene Propylene Diene Monomer), a type of synthetic rubber known for its excellent resistance to weather, ozone, heat, and chemicals.
Applications: It can handle air, water, light chemicals, and non-corrosive liquids, making it ideal for tasks like irrigation, construction, and even for use with air tools such as nailers and staplers
Features: The hose is highly resistant to abrasion and can tolerate both hot and cold water. It is also widely used for suction and delivery operations
Flexibility: Its flexibility and resistance to wear make it suitable for delivering fertilizers, acids, and general-purpose air and water tasks
Product Parameters:
| 1/4'' Flame Resistance EPDM Breathing Hose | |
| Application | For conveying oxygen and supporting in firefighting, chemical and other special industrial applications, and safe oxygen for the human body. |
| Color | Black (Customized) |
| TEMP. Rang | -40ºC~100ºC / -40ºF~+212ºF |
| Inner Diameter | 1/4'' (6.3mm) |
| Certifications | CE & RoHS approved. |
| Material | High-quality EPDM Synthetic Rubber |
| Reinforcement | High tensile polyester fiber braided |
| Length | 50/100 meters/roll |
| Grade | UL94-V0 |
| Specific Parameters | |||||||||||
| Part Number | I.D | O.D | Max W.P. | Min B.P. | Min Bend Radius | Weight | |||||
| NO. | inch | mm | inch | mm | psi | bar | psi | bar | inch | mm | kg/meter |
| PMP-05 | 3/16 | 4.8 | 0.43 | 11.0 | 300 | 20 | 900 | 60 | 1.57 | 40 | 0.12 |
| PMP-06 | 1/4 | 6.3 | 0.51 | 13.0 | 300 | 20 | 900 | 60 | 1.97 | 50 | 0.15 |
| PMP-08 | 5/16 | 8.0 | 0.59 | 15.0 | 300 | 20 | 900 | 60 | 2.36 | 60 | 0.20 |
| PMP-10 | 3/8 | 10.0 | 0.67 | 17.0 | 300 | 20 | 900 | 60 | 2.76 | 70 | 0.23 |
Applications:
Advantages:
1. No bulge
2. Anti-kink
3. Non Conductive
4. High Flexibility
5. Wear Resistance
6. Aging Resistance
